Horizontal Pin Header
Features & Benefits
- Zierick’s Horizontal Header is easily customized for a combination of different pin lengths and missing pins for proper mating connector orientation.
Specification
| Packaging Type | Loose |
|---|---|
| Finish Specification | Tin Plated |
| Current Rating | 8/Pin |
| Number of Rows | 1 |
| Pins per Row | 3 |
| Pin Length (L) | 0.500" (12.70mm) |
| Zierick recommends .006" (0.15mm) stencil thickness for most applications. For other stencil thicknesses\\, call Zierick's product development department. | 1 |
